linPHa UNDER
linPHa UNDER is a fridge-carbonator that can be easily installed under your kitchen sink.
linPHa UNDER is characterized by an attractive design, very low noise and almost zero heat variations thanks to the liquid cooling system it is equipped with. The distinctive feature of linPHa UNDER is the ability to continuously dispense up to 2 liters of sparkling water, which makes it a one-of-a-kind machine.
Product Features
for linPHa UNDER
Personalization
The front part can be customized according to various needs, both with a methacrylate panel in various colors and shades, and with stickers, with the possibility of applying laser engravings, with a company logo, product name or other, according to the customer’s instructions.
Standard Color Black
It is possible to make both the body and the front panel in different colors on request with minimum quantity. Polished stainless steel body available on request.
Electronic Control
- Electronic control unit
- Backlit display
- Filter replacement alarm
- Flood warning
- Automatic membrane washing
A Personalized Solution for You!
Each person is unique, and with the VSW Purifier, you can request customized coding tailored to your specific needs.
linPHa UNDER Technical Data
| Technical features | linPHa UNDER Osmo | linPHa UNDER Micro |
|---|---|---|
| Diet | 230v 50Hz | 230v 50Hz |
| Absorption | 200W (in operation) | 200W (in operation) |
| Pump | Booster 900 GPD SHP 36V 8bar | Booster 900 GPD SHP 36V 8bar |
| Nominal production at 25°C | 120-200 l/h | – |
| Rejection rate | 95/98% | – |
| Membranes | 2 CSG-K™ 200 GPD membranes | – |
| Permeate discharge ratio | 1/1 | – |
| Pump start delay | ✓ | ✓ |
| BYPASS TDS regulation | ✓ | – |
| Daphne™ Under Osmo Dimensions | H 43 x W 19 x D 44 cm | H 43 x W 19 x D 32 cm |
| Weight | 25 Kg | 20 Kg |
Available Versions:
linPHa UNDER: still and sparkling osmotized water.
linPHa UNDER Micro: still and sparkling microfiltered water with pre-filtration.
Accesories Included:
- Electric Cable
- Water mains connection fittings kit
– Food grade PE pipes
